PERFORMANCE TABLE
Borewell Size :200.0 mm
Pump O.D. : 195.0 mm
Motor O.D.: 186.0 mm
Sr. No. Pump Type HP. Stage Delivery Size 75 mm (3”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
90 250 640 700 860 960 1100
1 NM8-30 10 3 Total Head in Meters 53 51 46 42 32 16 2 S / D 4
2 NM8-30 12.5 4 72 69 63 56 42 22 3 S / D 4
3 NM8-30 15 5 88 85 77 70 52 28 4 S / D 4
4 NM8-30 17.5 6 107 102 92 84 63 35 5 S / D 6
5 NM8-30 20 7 125 120 106 96 72 40 6 S / D 6
6 NM8-30 25 8 143 137 123 112 84 44 7 S / D 10
7 NM8-30 30 10 178 171 151 137 103 55 8 S / D 10
8 NM8-30 36 12 213 205 180 164 123 66 10 A.T.S. 16
9 NM8-30 40 13 231 222 198 180 135 72 11 A.T.S. 16
10 NM8-30 45 14 249 239 206 196 147 77 12 A.T.S. 25
11 NM8-30 45 15 267 256 229 208 156 83 13 A.T.S. 25
Sr. No. Pump Type HP. Stage Delivery Size 75 mm (3”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
160 430 760 880 1070 1370 1600
1 NM8-40 7.5 2 Total Head in Meters 39 35 31 28 21 11 1 DOL / SD 4 / 4
2 NM8-40 12.5 3 53 53 46 42 32 17 2 S / D 4
3 NM8-40 15 4 78 70 62 56 42 22 3 S / D 4
4 NM8-40 20 5 98 87 77 70 53 28 4 S / D 6
5 NM8-40 25 6 118 105 92 84 63 34 5 S / D 6
6 NM8-40 30 7 137 122 108 98 74 39 6 S / D 10
7 NM8-40 30 8 157 140 123 112 84 45 7 S / D 10
8 NM8-40 36 9 176 157 139 126 94 50 8 A.T.S. 16
9 NM8-40 40 10 196 175 154 140 105 56 9 A.T.S. 16
10 NM8-40 45 12 236 230 185 168 126 68 10 A.T.S. 25
Sr. No. Pump Type HP. Stage Delivery Size 100 mm (4”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
210 510 1000 1180 1380 1670 1930
1 NM8-50 10 2 Total Head in Meters 37 35 31 28 21 11 5 S / D 4
2 NM8-50 15 3 55 53 46 42 32 17 8 S / D 4
3 NM8-50 20 4 74 70 62 56 42 22 10 S / D 6
4 NM8-50 25 5 93 87 77 70 53 28 13 S / D 6
5 NM8-50 30 6 111 105 92 84 63 34 15 S / D 10
6 NM8-50 36 7 129 122 108 98 74 39 18 A.T.S. 16
7 NM8-50 40 8 148 140 123 112 84 45 20 A.T.S. 16
8 NM8-50 45 9 166 157 139 126 94 50 23 A.T.S. 25
9 NM8-50 50 10 196 175 154 140 105 56 25 A.T.S. 25
Sr. No. Pump Type HP. Stage Delivery Size 100 mm (4”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
270 900 1220 1330 1540 1820 2040
1 NM8-60 12.5 2 Total Head in Meters 40 35 31 28 21 11 1 S / D 4
2 NM8-60 17.5 3 60 53 46 42 32 17 2 S / D 6
3 NM8-60 25 4 80 70 62 56 42 22 3 S / D 6
4 NM8-60 30 5 99 87 77 70 53 28 4 S / D 10
5 NM8-60 36 6 119 105 92 84 63 34 5 A.T.S. 16
6 NM8-60 42 7 139 122 108 98 74 39 6 A.T.S. 25
7 NM8-60 50 8 148 140 123 112 84 45 7 A.T.S. 25
Sr. No. Pump Type HP. Stage Delivery Size 100 mm (4”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
70 320 1280 1500 1760 2030 2250
1 NM8-70 15 2 Total Head in Meters 40 39 34 31 23 12 2 S / D 4
2 NM8-70 20 3 61 59 52 47 35 19 3 S / D 6
3 NM8-70 30 4 82 79 69 63 47 25 4 S / D 10
4 NM8-70 36 5 101 98 96 78 58 31 5 A.T.S. 16
5 NM8-70 42 6 122 117 103 94 70 38 6 A.T.S. 25
6 NM8-70 50 7 140 136 120 126 94 44 7 A.T.S. 25
Sr. No. Pump Type HP. Stage Delivery Size 125 mm (5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
80 220 1280 1660 1930 2230 2440
1 NM8-80 15 2 Total Head in Meters 40 39 34 31 23 12 2 S / D 4
2 NM8-80 25 3 61 59 52 47 35 19 3 S / D 6
3 NM8-80 31 4 82 79 69 63 47 25 4 S / D 10
4 NM8-80 42 5 101 98 86 78 58 31 5 A.T.S. 25
5 NM8-80 50 6 122 117 103 94 70 38 6 A.T.S. 25
Sr. No. Pump Type HP. Stage Delivery Size 125 mm (5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
250 920 1600 1820 2050 2250 2550
1 NM8-90 17.5 2 Total Head in Meters 42 39 34 31 23 12 2 S / D 6
2 NM8-90 30 3 64 59 52 47 35 19 3 S / D 10
3 NM8-90 36 4 85 79 69 63 47 25 4 A.T.S. 16
4 NM8-90 45 5 106 98 86 78 58 31 5 A.T.S. 25
Sr. No. Pump Type HP. Stage Delivery Size 125 mm (5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
350 1020 1700 1940 2150 2350 2650
1 NM8-100 20 2 Total Head in Meters 42 40 35 32 23 12 2 S / D 6
2 NM8-100 30 3 64 60 52 48 35 19 3 S / D 10
3 NM8-100 40 4 85 80 70 64 47 25 4 A.T.S. 16
4 NM8-100 50 4 106 100 88 80 58 31 5 A.T.S. 25
Sr. No. Pump Type HP. Stage Delivery Size 125 mm (5”) Performance Values Method of Starting Recom. Cable in sq. mm
Discharge in L.P.M.
1000 1910 2250 2470 2710 2840 2940
1 NM8-120 25 2 Total Head in Meters 40 35 32 29 24 20 2 S / D 6
2 NM8-120 36 3 60 52 48 44 36 30 3 A.T.S. 16
3 NM8-120 50 4 80 70 64 58 48 40 4 A.T.S. 25
